Kubernetes on VirtualBox: A Step-by-Step Guide

Hey guys! Ever wanted to dive into the world of Kubernetes but felt intimidated by complex cloud setups? Well, you're in luck! This guide will walk you through creating a Kubernetes cluster right on your own machine using VirtualBox. It's a fantastic way to learn, experiment, and get comfortable with Kubernetes without spending a dime on cloud resources. So, let's get started!

Prerequisites

Before we jump in, make sure you have these tools installed and ready to go:

  • VirtualBox: You'll need VirtualBox to create and manage your virtual machines. Download the latest version from the official VirtualBox website and install it. It's pretty straightforward, just follow the on-screen instructions.
  • kubectl: This is the Kubernetes command-line tool. It allows you to interact with your Kubernetes cluster. You can download it from the Kubernetes website or use a package manager like apt or brew, depending on your operating system.
  • Minikube (Optional): While we're focusing on a multi-node cluster, having Minikube installed can be helpful for quick tests and experiments. It's a single-node Kubernetes cluster that's super easy to set up.
  • A Text Editor: Any text editor will do, like VS Code, Sublime Text, or even Notepad. You'll need it to edit configuration files.
  • Sufficient System Resources: Running multiple VMs for a Kubernetes cluster requires some decent hardware. Make sure your machine has enough RAM (at least 8GB, preferably 16GB or more) and CPU cores (at least 4, more is better). Also, ensure you have enough disk space.

Step 1: Creating the Virtual Machines

First, you will need to create the virtual machines (VMs) that will form your Kubernetes cluster. We’ll set up one master node and two worker nodes for a basic cluster. This setup is great for learning and experimenting. Let's dive in!

Creating the Master Node VM

  1. Open VirtualBox and click on the "New" button to create a new VM.
  2. Name your VM something descriptive, like "k8s-master". Choose Linux as the type and Ubuntu (64-bit) as the version. Ubuntu Server is a good choice because it's lightweight and widely used.
  3. Allocate Memory: Give the master node at least 2GB of RAM. More RAM will improve performance, especially if you plan to run many applications on your cluster.
  4. Create a Virtual Hard Disk: Choose to create a virtual hard disk now. VDI (VirtualBox Disk Image) is the default and works well. Select "Dynamically allocated" so that the disk space is only used as needed. Allocate at least 20GB of disk space. Kubernetes and its associated containers can take up a considerable amount of space, especially when pulling images and running applications.
  5. Network Configuration: After the VM is created, go to its settings. Under the "Network" tab, attach the adapter to "Bridged Adapter". This allows the VM to get an IP address from your home network, making it easier to access from your host machine. Select the correct network interface that your host machine uses to connect to the internet. Make sure that the Promiscuous Mode is set to "Allow All".

Creating the Worker Node VMs

Repeat the process above to create two more VMs for the worker nodes. Name them something like "k8s-worker-1" and "k8s-worker-2". Allocate at least 2GB of RAM and 20GB of disk space for each worker node. Configure the network settings for each worker node in the same way as the master node, using a bridged adapter and allowing all promiscuous mode traffic. These worker nodes will be responsible for running the containerized applications managed by Kubernetes.

Installing Ubuntu Server on Each VM

  1. Download Ubuntu Server: Download the ISO image of Ubuntu Server from the official Ubuntu website. Make sure to download the 64-bit version.
  2. Mount the ISO: In the settings of each VM, go to the "Storage" tab. Under "Controller: IDE", click on the empty CD icon. Then, click on the CD icon next to "Optical Drive" and choose "Choose a disk file". Select the Ubuntu Server ISO you downloaded.
  3. Start the VM: Start each VM and follow the on-screen instructions to install Ubuntu Server. When prompted, create a user account and set a password. Choose the option to install the OpenSSH server so you can remotely access the VMs via SSH.
  4. Networking During Installation: During the installation, the installer will try to configure the network automatically. If it fails, you may need to manually configure the network settings. Use the bridged adapter configuration to obtain an IP address automatically via DHCP. Note down the IP addresses assigned to each VM. You will need them later to configure Kubernetes.
  5. Post-Installation Steps: After the installation is complete, reboot each VM. Log in with the user account you created. Update the package list and upgrade the installed packages to the latest versions using the following commands:
sudo apt update
sudo apt upgrade -y

This ensures that the VMs have the latest security patches and software updates.

Step 2: Configuring the Kubernetes Cluster

Alright, with our VMs up and running, it's time to configure the Kubernetes cluster. This involves setting up the master node, joining the worker nodes, and verifying the cluster's health. Let's get into the details!

Setting Up the Master Node

  1. SSH into the Master Node: Use SSH to connect to the master node VM from your host machine. Open a terminal or command prompt and use the following command:
ssh username@master_node_ip

Replace username with your user account name and master_node_ip with the IP address of the master node VM. Make sure you can successfully connect to the master node before proceeding. 2. Install Docker: Kubernetes uses Docker to run containerized applications. Install Docker on the master node using the following commands:

sudo apt update
sudo apt install docker.io -y
sudo systemctl start docker
sudo systemctl enable docker

These commands update the package list, install Docker, start the Docker service, and enable Docker to start automatically on boot. 3. Install kubeadm, kubelet, and kubectl: These are the essential Kubernetes components. Install them using the following commands:

sudo apt update
sudo apt install apt-transport-https ca-certificates curl -y
curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
echo "deb https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee -a /etc/apt/sources.list.d/kubernetes.list
sudo apt update
sudo apt install kubelet kubeadm kubectl -y
sudo apt-mark hold kubelet kubeadm kubectl

These commands add the Kubernetes package repository, install kubelet, kubeadm, and kubectl, and prevent them from being automatically updated. 4. Initialize the Kubernetes Cluster: Use kubeadm to initialize the Kubernetes cluster on the master node. Run the following command:

sudo kubeadm init --pod-network-cidr=10.244.0.0/16

The --pod-network-cidr flag specifies the IP address range for the pod network. This range should not overlap with any existing network ranges in your environment. Note the kubeadm join command that is printed at the end of the output. You will need this command to join the worker nodes to the cluster. 5. Configure kubectl: Configure kubectl to connect to the Kubernetes cluster. Run the following commands:

mkdir -p $HOME/.kube
sudo cp /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

These commands create the .kube directory in your home directory, copy the Kubernetes configuration file to it, and set the correct ownership permissions. 6. Install a Pod Network Add-on: A pod network add-on is required to enable communication between pods in the cluster. We will use Calico in this example. Install Calico using the following command:

kubectl apply -f https://docs.projectcalico.org/manifests/calico.yaml

This command applies the Calico manifest file to the cluster, installing the necessary components for the pod network.

Joining the Worker Nodes

  1. SSH into Each Worker Node: Use SSH to connect to each worker node VM from your host machine. Use the following command:
ssh username@worker_node_ip

Replace username with your user account name and worker_node_ip with the IP address of the worker node VM. Make sure you can successfully connect to each worker node before proceeding. 2. Install Docker: Install Docker on each worker node using the same commands as on the master node:

sudo apt update
sudo apt install docker.io -y
sudo systemctl start docker
sudo systemctl enable docker
  1. Install kubeadm, kubelet, and kubectl: Install kubeadm, kubelet, and kubectl on each worker node using the same commands as on the master node:
sudo apt update
sudo apt install apt-transport-https ca-certificates curl -y
curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
echo "deb https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee -a /etc/apt/sources.list.d/kubernetes.list
sudo apt update
sudo apt install kubelet kubeadm kubectl -y
sudo apt-mark hold kubelet kubeadm kubectl
  1. Join the Worker Nodes to the Cluster: Use the kubeadm join command that was printed when you initialized the cluster on the master node to join each worker node to the cluster. The command will look something like this:
sudo kubeadm join <master-node-ip>:6443 --token <token> --discovery-token-ca-cert-hash sha256:<hash>

Replace <master-node-ip>, <token>, and <hash> with the values from the kubeadm join command output. Run this command on each worker node. This will configure the worker nodes to connect to the master node and join the Kubernetes cluster.

Verifying the Cluster

  1. Check Node Status: On the master node, run the following command to check the status of the nodes in the cluster:
kubectl get nodes

This command will display a list of the nodes in the cluster, along with their status. Make sure that all nodes are in the Ready state. 2. Check Pod Status: Run the following command to check the status of the pods in the cluster:

kubectl get pods --all-namespaces

This command will display a list of all the pods in the cluster, along with their status. Make sure that all the essential pods, such as the coredns pods and the calico pods, are in the Running state.

Step 3: Deploying a Sample Application

Now that our cluster is up and running, let's deploy a simple application to test it out. We'll use a basic Nginx deployment for this example.

  1. Create a Deployment: Create a YAML file named nginx-deployment.yaml with the following content:
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 2
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:latest
        ports:
        - containerPort: 80

This file defines a deployment named nginx-deployment with two replicas. Each replica runs an Nginx container listening on port 80. 2. Apply the Deployment: Apply the deployment to the cluster using the following command:

kubectl apply -f nginx-deployment.yaml

This command creates the deployment in the cluster. 3. Create a Service: Create a YAML file named nginx-service.yaml with the following content:

apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  selector:
    app: nginx
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: NodePort

This file defines a service named nginx-service that exposes the Nginx deployment on port 80. The type: NodePort setting makes the service accessible from outside the cluster. 4. Apply the Service: Apply the service to the cluster using the following command:

kubectl apply -f nginx-service.yaml

This command creates the service in the cluster. 5. Access the Application: To access the Nginx application, find the NodePort that was assigned to the service using the following command:

kubectl get service nginx-service

The output will show the NodePort assigned to the service. Then, open a web browser and navigate to http://<worker-node-ip>:<nodeport>, replacing <worker-node-ip> with the IP address of one of the worker nodes and <nodeport> with the NodePort number. You should see the default Nginx welcome page.

Conclusion

And there you have it! You've successfully created a Kubernetes cluster on VirtualBox. This setup allows you to explore Kubernetes concepts, deploy applications, and experiment with different configurations without needing a cloud environment. Remember to practice, experiment, and dive deeper into the world of Kubernetes. Happy clustering!

Pro Tip: Don't be afraid to break things! The best way to learn is by experimenting and figuring out how to fix problems. Good luck, and have fun with your new Kubernetes cluster!
