Kubernetes Cluster Setup On Ubuntu 20.04: A Step-by-Step Guide

Nov 3, 2025 by Team 63 views

So, you're looking to dive into the world of Kubernetes, huh? Awesome! Getting a Kubernetes cluster up and running on Ubuntu 20.04 might seem daunting at first, but trust me, it's totally doable. This guide will walk you through each step, making the process as smooth as possible. We'll cover everything from installing the necessary components to deploying your first application. Let's get started!

Prerequisites

Before we jump into the setup, let's make sure you have everything you need. You'll want at least two Ubuntu 20.04 servers (or VMs). One will act as the master node, and the other(s) will be worker nodes. Here’s a quick checklist:

Ubuntu 20.04 Servers: At least two, with one designated as the master node.
User with sudo privileges: Make sure you can run commands with sudo.
Internet Connection: For downloading packages.
Basic Linux Knowledge: Familiarity with the command line is helpful.
Unique Hostnames and Static IPs: Each node should have a unique hostname and a static IP address.

Having these prerequisites in place will ensure that you have a smooth journey setting up your Kubernetes cluster. Trust me, skipping these steps can lead to a lot of headaches later on, so double-check everything!

Step 1: Install Container Runtime (Docker)

Okay, first things first, let's install Docker. Kubernetes needs a container runtime to run your applications, and Docker is a popular choice. Here’s how you do it:

Update Package Index:
```
sudo apt update
```
Keeping your package index up-to-date ensures you get the latest versions of software. It's like cleaning your room before starting a new project – good practice!
Install Docker:
```
sudo apt install docker.io -y
```
This command installs Docker from the Ubuntu repositories. The -y flag automatically confirms the installation, saving you a keystroke. Efficiency is key, right?
Start and Enable Docker:
```
sudo systemctl start docker
sudo systemctl enable docker
```
These commands start the Docker service and ensure it starts automatically on boot. This is super important because you want Docker running all the time.
Verify Docker Installation:
```
docker --version
```
Running this command will display the Docker version, confirming that Docker is installed correctly. If you see the version number, you're golden!

Repeat these steps on all your nodes – master and worker nodes alike. You need Docker everywhere for Kubernetes to work its magic.

Step 2: Install Kubernetes Components (kubeadm, kubelet, kubectl)

Alright, now that Docker is up and running, let's install the Kubernetes components. We're talking about kubeadm, kubelet, and kubectl. Here’s the lowdown:

Update Package Index:
```
sudo apt update
```
Yep, we're doing this again. Always a good idea to start with a fresh package index.
Install Required Packages:
```
sudo apt install apt-transport-https curl -y
```
These packages are needed to add the Kubernetes repository. apt-transport-https allows apt to access repositories over HTTPS, and curl is a tool for transferring data with URLs.
Add Kubernetes Repository:
```
curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
echo "deb https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee /etc/apt/sources.list.d/kubernetes.list
```
This adds the Kubernetes repository to your system. The first command downloads the Kubernetes signing key and adds it to your system's trusted keys. The second command adds the Kubernetes repository to your APT sources.
Update Package Index (Again!):
```
sudo apt update
```
Now that we've added the Kubernetes repository, we need to update the package index again to include the new packages.
Install kubelet, kubeadm, and kubectl:
```
sudo apt install kubelet kubeadm kubectl -y
sudo apt-mark hold kubelet kubeadm kubectl
```
This installs the Kubernetes components. kubelet is the agent that runs on each node, kubeadm is a tool for bootstrapping Kubernetes clusters, and kubectl is the command-line tool for interacting with the cluster. The apt-mark hold command prevents these packages from being automatically updated, which can cause issues with your cluster.

Repeat these steps on all your nodes. Consistency is key!

Step 3: Initialize the Kubernetes Master Node

Now comes the exciting part – initializing the Kubernetes master node! This is where the magic happens. Here’s how to do it:

Initialize the Master Node:
```
sudo kubeadm init --pod-network-cidr=10.244.0.0/16
```
This command initializes the Kubernetes master node. The --pod-network-cidr flag specifies the network range for pods. This example uses 10.244.0.0/16, which is the default for Calico (a network plugin we’ll install later).
Configure kubectl:

After the kubeadm init command completes, it will output some instructions. Follow those instructions to configure kubectl for your user:
```
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config
```
These commands copy the Kubernetes configuration file to your user's home directory and set the correct permissions. This allows you to use kubectl to interact with your cluster.
Deploy a Pod Network:

Kubernetes needs a pod network to allow pods to communicate with each other. We'll use Calico, a popular and easy-to-use network plugin:
```
kubectl apply -f https://docs.projectcalico.org/manifests/calico.yaml
```
This command deploys Calico to your cluster. It might take a few minutes for all the pods to become ready.
Verify the Master Node:
```
kubectl get nodes
```
This command will show you the status of your nodes. The master node should be in the Ready state. If it’s not, give it a few minutes and try again.

Step 4: Join Worker Nodes to the Cluster

With the master node up and running, it's time to add the worker nodes. This is how you make your cluster truly useful. Here’s the process:

Get the Join Command:

When you initialized the master node, kubeadm init output a kubeadm join command. It looks something like this:
```
kubeadm join <master-ip>:<master-port> --token <token> --discovery-token-ca-cert-hash sha256:<hash>
```
If you don't have this command, you can regenerate it on the master node:
```
kubeadm token create --print-join-command
```
Run the Join Command on Worker Nodes:

Copy the kubeadm join command and run it on each of your worker nodes. This command tells the worker nodes to join the cluster managed by the master node.
Verify the Worker Nodes:

Back on the master node, run:
```
kubectl get nodes
```
You should now see your worker nodes listed, along with the master node. They should all be in the Ready state.

Step 5: Deploy a Sample Application

Now that your cluster is up and running, let’s deploy a sample application to make sure everything is working as expected. We'll deploy a simple Nginx deployment.

Create a Deployment:
```
kubectl create deployment nginx --image=nginx
```
This command creates a deployment named nginx using the nginx image from Docker Hub.
Expose the Deployment:
```
kubectl expose deployment nginx --port=80 --type=NodePort
```
This command exposes the nginx deployment on port 80 using a NodePort service. NodePort makes the service accessible on each node's IP address at a specific port.
Get the Service Information:
```
kubectl get service nginx
```
This command will show you the service information, including the NodePort. It will look something like 30000-32767.
Access the Application:

Open a web browser and navigate to http://<node-ip>:<node-port>, where <node-ip> is the IP address of one of your nodes and <node-port> is the NodePort you obtained in the previous step. You should see the default Nginx welcome page.

Conclusion

And there you have it! You've successfully set up a Kubernetes cluster on Ubuntu 20.04. You've installed Docker, configured the Kubernetes components, initialized the master node, joined the worker nodes, and deployed a sample application. Give yourself a pat on the back!

This is just the beginning, though. Kubernetes is a powerful platform with a lot to offer. Keep exploring, keep learning, and keep building! There's a whole world of Kubernetes features waiting for you to discover, from advanced networking to persistent storage and beyond. So, what are you waiting for? Go explore and have fun!
